UHF RFID Portal Reader with Aluminum ABS LINUX System High Performance

Product Description:

RFID Gate Reader is an advanced RFID portal reader designed to quickly identify and scan RFID tags. The product supports ISO18000-6C protocol, the working frequency band supports the national standard 920MHz ~ 925MHz, FCC 902MHz ~ 928MHz, the output power is 0dBm ~ 33dBm optional; Built-in phased combination antenna, aided by positioning algorithm can judge the direction of label movement, accurately distinguish between the field and the off-site label, anti-leakage reading and misreading performance is good, with non-inductive trigger, identification distance, multi-label recognition ability, strong anti-interference ability, good scalability and easy installation and use. The structure can be mounted on the top or side, and the installation height can reach up to 5m.

Features:

 Supports the server mode for multi-channel control
 Supports the EPC C1 G2 (ISO18000-6C) protocol
 Operating frequency 902~928MHz (customizable 865~868MHz)
 built-in phased combination antenna, can judge the label moving direction; The top mounting height is 3-5 meters, and the covering channel width is 2.5 to 3 meters
 Built-in Linux operating system 4.1.15 and middleware, easy to customize application development;
 Support ceiling, ceiling and wall mounted installation, fast and convenient greatly reduce equipment installation costs;
 built-in alarm light and buzzer, support a variety of combination events sound and light alarm, support online and offline alarm;
Supports multi-channel GPIO input and output, and can integrate peripheral devices according to application scenarios.​

Technical Parameters:

Applications:

The RFID Gate Reader, Model Number BRC-05A Pro, is a high-end UHF RFID Access Portal that is used for access control applications. With its Phased Combination Antenna and advanced algorithms, it is able to read multiple tags in a single pass. It is made of premium quality Aluminum + ABS material to ensure durability and reliability. It has a storage temperature range of -30℃～70℃ and a size of 440mm×210mm×40mm (without support).

This RFID Gate Reader is manufactured by rfid, a well-known brand in the RFID industry. It has a minimum order quantity of 1pcs and is available at a price of 980. It comes in a standard export carton, with foam and protective film for extra protection. Delivery can be expected within 7 working days.

It can be widely used in clothing retailers, books and archives management, personnel access management, fixed assets, intelligent warehousing management and other fields.

Support and Services:

RFID Portal Reader provides technical support and services to ensure that our customers have a seamless experience when using our products. Our technical support team is available to provide assistance via phone, email, and live chat, as well as offer detailed technical documentation. Our services include installation, configuration, and training to ensure that your company is getting the most out of our products. We also offer maintenance and repair services to keep your RFID Portal Reader running smoothly. Our team is always available to provide quick and effective solutions to any issues or questions you may have.

Packing and Shipping:

Before packaging and shipping, RFID Portal Reader should be tested to ensure proper functioning.

• Check that the RFID Portal Reader is undamaged before packing.
• Pack the RFID Portal Reader securely in an appropriate box.
• Seal the package with tape for extra protection.
• Label the package with the recipient's address and other relevant information.

• Choose an appropriate shipping method.
• Contact the shipping company to arrange for pickup.
• Provide a tracking number to the recipient.

FAQ:

• Q: What is the Brand Name of the RFID Portal Reader?
  A: The Brand Name of the RFID Portal Reader is Bowei.
• Q: What is the Model Number of the RFID Portal Reader?
  A: The Model Number of the RFID Portal Reader is BRC-05A Pro.
• Q: Where is the RFID Portal Reader manufactured?
  A: The RFID Portal Reader is manufactured in Shenzhen.
• Q: What is the minimum order quantity for the RFID Portal Reader?
  A: The minimum order quantity for the RFID Portal Reader is 1pcs.
• Q: How much does the RFID Portal Reader cost?
  A: The RFID Portal Reader costs 980.
• Q: What kind of packaging does the RFID Portal Reader come in?
  A: The RFID Portal Reader comes in Standard Export Carton, Foam and Protective Film.
• Q: How long does it take for the RFID Portal Reader to be delivered?
  A: It takes 7 working days for the RFID Portal Reader to be delivered.
