Long Range Wide Beam UHF RFID Antenna High Gain Circular Polarization UHF Directional Antenna for Logistics

Long Range Wide Beam UHF RFID Antenna High Gain Circular Polarization UHF Directional Antenna for Logistics

Long Range Wide Beam UHF RFID Antenna High Gain Circular Polarization UHF Directional Antenna for Logistics
video
Long Range Wide Beam UHF RFID Antenna High Gain Circular Polarization UHF Directional Antenna for Logistics
Product Details:
Place of Origin: Shenzhen, China
Brand Name: Broadradio
Model Number: BRA-15
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Standard Export Carton, Foam and Protective Film
Delivery Time: 3-5works
Payment Terms: T/T, Paypal
Contact Now
Detailed Product Description
Name: Narrow Beam Antenna Frequency Range: 902MHz~928MHz
Gain: >8dBic Polarization: Circular Polarization
Front-to-Back Ratio: 20dB Size: 200mm×200mm×32mm
Weight: 0.85kg (bracket Excluded) Email: Lyh@brrfid.com

BRA-15 UHF RFID Narrow beam antenna Anti-impact anti-vibration with medium size



Product Model

BRA-15 Antenna

Product Function and Features

Impact resistance, anti-vibration, wide beam, high gain, low VSWR and etc.;

Pleasing appearance with small size, double waterproof design with waterproof ring and silica gel, rib reinforcement design for shell, suitable for various severe environments.

Product Applications

BRA-15 Antenna is of convenient application in access control, warehousing, logistics, retail and other UHF RFID application fields.



Performance Specifications

Frequency Range 902MHz~928MHz
VSWR ≤1.3:1

Gain

>8dBic

Beamwidth

89°x89°

Polarization

Circular Polarization

Front-to-Back Ratio

20dB

Relative humidity 5%~95%
Impedance 50±1Ω
Connector Type

RP-TNC Female



Mechanical Specifications

Size 200mm×200mm×32mm
Weight 0.85kg (bracket excluded)
Material

Aluminum alloy, engineering plastics ASA

Color

Milk-white

Production Class IP65
Operating Temperature -40℃~+ 85℃
Storage Temperature -40℃~+ 85℃



Long Range Wide Beam UHF RFID Antenna High Gain Circular Polarization UHF Directional Antenna for Logistics 0

Figure 1. Antenna Photo



Mounting Dimensions

BRA-15 mounting dimensions



Broadradio is a high-tech enterprise focusing on RFID, production and sales of UHF rfid hardware for 10 years. It has excellent independent innovation capability, obtained many national and international patents, and has more than 10,000 square meters of R&D production in South China Base. more than 500 production staff to ensure production capacity, and equipped with more than 20 high-standard test equipment to ensure product quality, is your ideal partner.
